商品详细
| 型号 (Model) | 80800940 |
| 处理器架构 (CPU Socket) | Intel Socket 2011 Narrow ILM |
| 机箱架构 (Solution) | 2U Server and Up ( Active ) |
| 尺寸 (Dimensions) | 103.75 x 76.7 x 69.0 mm |
| 功耗 (TDP) | 145W |
| 材质 (Material) | AL Base+AL Fin+ 4HP + 6025 Fan |
| 导热膏 (Thermal Grease) | ShinEtsu X23-7783D Pre-Applied |
| 风扇型号 (Fan P/N) | TD6025B12MA |
| 额定电压 (Rated Voltage) | 12 VDC |
| 启动电压 (Starting Voltage) | 7.0 VDC |
| 额定电流 (Rated Current) | 0.45 A |
| 转速(Speed) | 6800±10% RPM |
| 轴承 (Bearing) | Two Ball |
| 风量 (Air Flow) | 41.4 CFM |
| 风压 (Static Pressure) | 14.74 mm H2O |
| 噪音 (Noise) | 47.67 dBA |
| PWM 功能 (PWM Function) | PWM Control |
| 安规认证 (Safety Approval) | UL & CE |
| 环保等级 ( Environmental Level) | RoHS 2.0 |
| 接插端子 (Connector Housing) | 2510 – 4Pin; Pin1,4防呆 |
